SKU: 1185 ANMOD1-WC or ANMOD1-WC-CR Category: Tag:

Spread the love

Product Specifications:
The MOD1 has a very wide power band that makes slightly more top end than the 308 grind, and is easy on the valve train. The MOD1 requires an upgraded spring package, billet rod, and billet flywheel.
The Lobes on this Cam are Welded for extra durability.
Available with or without compression release installed
Grind Number : MOD1
Engine: Intek OHV
Recommended Class: Modified
Target (Max) RPM: 9000Spring Pressure (In / Ex): 34-36 lbsValve Lash (In / Ex): .003″Ignition Timing: 30-32 Deg BTDC
Valve TimingIntakeExhaustOpen42.0 BTDC78.0 BBDCClose 83.5 ABDC46.0 ATDCLift.310″.310″C/L108.0 ATDC108.0 BTDCDUR @ 50:247.6 Deg247.6 Deg
