??Fits (For the reference)??Atomik, Pitpro, TDR, Hummer, Orion, Xmoto, Lei,Dmx, Swd, Tommahawk, Monsoon, Grudge, Kazuma, Bull,Trooper, Hunter, Motox, Trojan, Blitz, Crusade, Link, Bigfoot, Kuda, Motorworks, Nitrous, Reign, ddr, Fury, Prox,Raider, Zongshen, Chongqing, Loncin, Ducar, Lifan, Gy6, Thumpster, Thumbstar, Go kart, Quad, Dirt bike, ATV,Pit bike, Dirt bike, Buggy, Pocket rocket.
??GEAR SYSTEM?? 3 FORWARD; UTRAL; REVERSE
??Type??Horizontal, single-cylinder, 4-stroke, air-cooled
??Power??Maximum t power/ rpm : 5.8 kw/ 7500r/ min??375 r/ min Maximum torque/ rpm : 8.5 N.m/5000r/min??250 r/min
?Note: Installation Manual Is NOT Included Professional Installation Is Highly Recommended
Product description
Color:Model??
Specifications:
ENGI SIZE : 125CC
Type : Horizontal, single-cylinder, 4-stroke, air-cooled
Start Method : Electrical Start
Bore x Stroke : 52.4 ?? 55.5 mm, 119.7 mL
Top Engi Mount : 92mm
Bottom Engi Mount: 82mm
Bolt to Bolt :152mm (6″)
Compression ratio : 9.0: 1
Maximum t power/ rpm : 5.8 kw/ 7500r/ min??375 r/ min
Maximum torque/ rpm : 8.5 N.m/5000r/min??250 r/min
Idle speed : 1500 r/min??100r/min
Front sprocket : 420 – 17mm – 14T
Ignition : CDI
Air Filter : 35mm
Carburetor : PZ19
Starter : Kick starter
Lubrication : Pressure/splash
Oil capacity : 900ml:
Fits (For the reference):
ENGI SIZE : 125CC
Wiring:
1. Five wires (Plug): For gear indicator
2. Yellow wire: For storage battery
3. Pink (or Yellow) wire: For storage battery
4. Black & Red wire: For signal trigger
5. Green wire: For grounding
6. Blue & White: For trigger coil
Package includes:
it comes with:Wiring+ carby+Airfilter+ Chain case + Gasket As you see in the picture
