Torque Converters

Features:
TAV2 30 Series Torque Converter Clutch Kit: This 3/4″ torque converter is a direct replacement go kart clutch set fits for 6.5hp 212CC engines (MAX 8HP) with 3/4″ engine shaft
Wide Application: Can be used in lawnmowers, go karts, mini bikes, ATV, motorcycles
Multi-function: This clutch will help you get more power out of your small engine by reducing engine load; gradually engage the engine and the transmission to ensure a smooth acceleration; play a protective role to prevent the engine and transmission from overloading
Durable: Made of aluminum material, which is sturdy, durable, maximum torque, wear-resisting and fast heat dissipation
All Mounting Hardware: This is a complete kit that includes both drive and driven clutch pulleys, belt, aluminum engine mounting plate, 12 teeth sprocket for #35 chain (Chain is not included)
Specifications:
Overall Dimension (LxWxH): 13 5/16″ x 7 1/2″ x 7 7/16″ (33.85 x 19.1 x 18.9 cm)
Front Clutch Size (LxWxH): 4 7/8″ x 4 7/8″ x 3 1/16″ (12.4 x 12.4 x 7.8 cm)
Rear Clutch Size (LxWxH): 6 1/4″ x 6 1/4″ x 2 9/16″ (15.8 x 15.8 x 6.5 cm)
Belt Folded Size (LxWxH): 11 13/16″ x 3 1/8″ x 13/16″ (30 x 8 x 2 cm)
Plastic Shell Size (LxWxH): 13 3/8″ x 7 1/2″ x 4 3/4″ (34 x 19 x 12 cm)
Aluminum Plate Size (LWxH): 12 15/16″ x 6 15/16″ x 2 15/16″ (32.9 x 17.7 x 7.5 cm)
Front Drive Clutch Bore: 3/4″
Rear Drive Clutch Bore: 5/8″ (Disk Dia.: 6″)
Sprocket: 12 Teeth
Engagement Range: 2350??200 RPM
Variable Speed Ratio 3.2 to 0.8
Material: Aluminum Clutch, Rubber Belt, Plastic Shell, Aluminum Plate
Net Weight: 11.02 Lbs (5 kg)
Package Contents:
1x Drive Belt
1x Plastic Cover
1x Front Clutch
1x Rear Clutch
1x 12 Teeth Sprocket
1x Aluminum Plate
1x Screw set
1x Manual
