Torque Converter 1 Inch Bore, Go Kart Kit W/10T for #40/41 Chain and 12T for #35 Chain,212CC 30 Series Go Kart Clutch Comet TAV2 Engine Drive Replacement Set

EXCELLENT MATERIAl- Our torque converter body is forged from high-quality iron and aluminum, which is wear-resistant, lightweight and does not add extra weight to the entire vehicle. It is lighter than traditional models and also saves fuel consumption.
Widely Fitment-Our torque converter is suitable for all engines with 1-inch straight crankshafts,fully compatible with Comet and TAV2,also apply to Manco go-karts.
REPLACEMENT MODEL- Comet 218353A, 219552A, 219456A, 217610A, 203814A, TAV2 30-75, Yelf Dog Drive Unit Q43201W.
EASY ASSEMBLY- The kit contains all the accessories needed to the installation, before installation, you need to read the instructions carefully in advance and just follow the instructions. Note that the distance between the centers of the two drives needs to be between 6 5/8 and 6 11/16.
This torque converter is suitable for all 1″ straight crankshaft engines. This torque converter is suitable for all 1 “straight crankshaft engines and is a direct replacement for the Comet TAV2 Kart Hydraulic Torque converter 30 series as well as Manco Go kart.

Specification

Material : Iron &Aluminum

Drive Clutch Bore:1 (25.4mm)

Driven Unit : Diameter 6″ (5/8″ Driven Pulley)

10 Tooth Sprocket : For #40/41/420 Chain

12 Tooth Sprocket : For #35 Chain

Driven Belt : Top Width 3/4″

Engagement Range : 2350 200 RPM

Recommend Engine : 2HP – 7HP

Replace Part Number : Comet 218353A, 219552A, 219456A, 217610A, 203814A, TAV2 30-75, Yelf Dog Drive Unit Q43201W

Package List1″ driver pulley x 15/8” driven pulley x 110 tooth sprocket x 112 tooth sprocket x 1Plastic assy cover x 1Driver belt x 1Aluminum mounting bracket plate x 1Full mounting hardware kit x 1
