Rear Axle Assembly Complete Wheel Hub Kit Set for Go Kart Quad Trike Drift Bikes

SKU ZhTJ.00226 Category Tag

SPREAD THE LOVE

Share on facebook
Share on twitter
Share on linkedin
Share on pinterest
Share on reddit
Share on odnoklassniki

Description

Features:
What you Get: 2* Wheels (with tire, rim, tube), 2* Pillow Block, 1* Axle Assembly, 1* T8F Chain, 1* Sprocket, 1* Brake Disc, 1* Brake Master Cylinder Caliper Assembly.Enough for your need.
High class and Durable: These have almost all the rear-end parts necessary needed, Suitable for DIY rebuild drift bikes, go kart quad, or trikes.
Shaft Size: The Shaft overall length: 740 mm (29.13 inch), Spline to Spline: 452 mm (17.79 inch), the thickest part of the shaft is 22 mm(0.86 inch), Bearing Position: 20 mm(0.78 inch).
Wheel Size:Diameter-13.0 inch , Width- 3.93 inch , come with 4.1-6 tire, 6″ rim, and inner tube.
Suitable: fits 6 inch wheels (rim) with 3 bolt pattern and 3 inch bolt to bolt space.
SPECIFICATION:
Chain and Sprocket: T8F
fits 6 inch wheels (rim) with 3 bolt pattern and 3 inch bolt to bolt space.
