Nickel Plated & Stainless Steel Chain
DESCRIPTION/
CHAIN SIZE
10′ BOX
BULK REELS
(PER FOOT)
CONNECTOR
LINKS
OFFSET
LINKS
Nickel Plated Roller Chain
#35 NP
4147-10
4147
4148
4149
#40 NP
4150-10
4150
4151
4152
#41 NP
4165-10
4165
4166
4167
#50 NP
4153-10
4153
4154
4155
#60 NP
4156-10
4156
4157
4158
#80 NP
4159-10
4159
4160
4161
#C2060 HNP

4162
4163
4164
#C2062 HNP

4240
4163

Stainless Steel Roller Chain
#35SS
4132-10
4132
4133
4134
#40SS
4020-10
4020
4021
4022
#50SS
4123-10
4123
4124
4125
#60SS
4126-10
4126
4127
4128
#80SS
4733-10
4733
4734
4735
Nickel Plated & Stainless Steel Chain C Strength & Dimensions
CHAIN NUMBER
PITCH
ROLLER
DIAMETER
BETWEEN INNER
PLATES
PIN
DIAMETER
AVERAGE
TENSILE
LBS. PER FOOT*
Nickel Plated Roller Chain
#35 NP
3/8
.200
3/16
.141
2,100
.22
#40 NP
1/2
.312
5/16
.156
3,700
.42
#41 NP
1/2
.306
1/4
.141
2,000
.28
#50 NP
5/8
.400
3/8
.200
6,100
.67
#60 NP
3/4
.468
1/2
.234
8,500
1.05
#80 NP
1
.625
5/8
.312
14,500
1.72
#C2060 HNP
1-1/2
.469
1/2
.234
8 ,500
1.05
#C2062 HNP
1-1/2
.875
1/2
.234
8,500
1.50
Stainless Steel Roller Chain
#35 SS
3/8
.200
3/16
.141
1,700
.22
#40 SS
1/2
.312
5/16
.156
3,100
.43
#50 SS
5/8
.400
3/8
.200
4,700
.72
#60 SS
3/4
.468
1/2
.234
7,000
1.01
#80 SS
1
.625
5/8
.312
14,000
1.70
*nominal
