SKU: 2105 3902-SS669-196 Category: Tag:

Spread the love

Steering Shaft for Coleman KT196 & HiSun HS200GK Go-Karts
This is the steering shaft for the Coleman KT196 & HiSun HS200GK go-karts.
Shaft details:
Overall length: 453mm [17.83″]
Shaft diameter: 16mm [.64″]
10mm x 1.25 threads on the bottom
Top of shaft has 57.2mm [2.25″] OD flange with 3 bolt holes.
Bolt holes are approximately 36.2mm [1.4″] center-to-center apart
Flange diameter: 57mm [2.25″]
Fits Coleman KT196 & HiSun HS200GK.
May fit other makes and models too. Please check description and pictures before ordering.
