Torque converter comes with a 10 Tooth sprocket for a #40/41/420 chain and a 12 Tooth sprocket for a #35 chain(chain not included). It will work with engi sizes 2HP to 8HP(6HP-6.5HP is the most suitable horsepower).
This 1″ Torque Converter is fullCompatible With:omet and TAV2 torque converters. It fits all engis with a 3/4″ straight crankshaft. Replaces Comet, also apply to Manco go-karts.
Unit replaces: Comet 218353A, 219552A, 219456A, 217610A, 203814A, TAV2 30-75, Yelf Dog Drive Unit Q43201W. 30 series of asymmetrical designs, some parts have been assembled.
The torque converter is made of high-quality iron and aluminu
Material:which is light, strong, and durable. The clutch obtains more power by reducing the engi load for smooth acceleration and gear shifting.
Our clutch kit obtains a 1″ driver clutch, a 5/8″ driven clutch, a plastic assy cover, an aluminum mounting plate, a drive belt(top width 3/4″), a 10 Tooth sprocket, a 12 Tooth sprocket, full mounting hardware.
This 1″ torque converter is a direc
REPLACEMENT:it for the most popular Comet TAV2 go-kart torque converter 30 series. This kit comes with two sprockets: a 12 Tooth sprocket for #35 chain, a 10 Tooth sprocket for #40/41 chain. It fits all engis with a 1″ straight crankshaft. Replaces Comet, Also Fits Manco Go Karts.Item Specificati
Material: Iron + AluminumDriver Unit : 1″(25.4 mm), 1/4 KeyDriven Unit : Diameter 6″ (5/8″ Driven Pulley)10 Tooth Sprocket : Fit #40/41/420 Chain12 Tooth Sprocket : Fit #35 ChainDriven Belt : Top Width 3/4″Engagement Range : 2350??200 RPMRecommend Engi : 2HP – 8HP (6HP-6.5HP is the most suitable horsepower)Replace Part Number : Comet 218353A, 219552A, 219456A, 217610A, 203814A, TAV2 30-75, Yelf Dog Drive Unit Q43201WPackage Content1″ driver pulley x 15/8″ driven pulley x 110 tooth sprocket x 112 tooth sprocket x 1Driver belt x 1Plastic assy cover x 1Aluminum mounting bracket plate x 1Full mounting hardware x 1
