Quality reproduction kit is a great low cost alternative for overhauling your chainsaw. We use our reproduction parts in our own shop.
YEAR INTRODUCED: 1981 ENGI DISPLACEMENT: 3.27 cu. in. (53.6 ccm) NUMBER OF CYLINDERS: Homelite Two-Cycle single cylinder loop scavenged engi CYLINDER BORE: 1.687 in. (43 mm) PISTON STROKE: 1.464 in. (37 mm) PISTON RING THICKSS: 2 rings, pn 93823 CYLINDER TYPE: Aluminum with Chrome plated bore INTAKE METHOD: Reed valves MANUFACTURER ADVERTISED H.P.: 3.29 SAE @ 8,000 RPM WEIGHT: 12 lbs. 8 oz. (5.7 kg) powerhead only OPERATOR CONFIGURATION: O Man operation HANDLEBAR SYSTEM: Rigid
CHAIN BRAKE:Optional, mechanical CLUTCH: Centrifugal, 3 metal shoes DRIVE TYPE: Direct CONSTRUCTION: Injection molded Polymer MAGTO TYPE: Flywheel Electronic CARBURETOR: Zama MAJOR REPAIR KIT: ZAMA MINOR REPAIR KIT ZAMA AIR FILTER SYSTEM: Nylon mesh cartridge STARTER TYPE: Homelite automatic rewind OIL PUMP: Automatic MAXIMUM ENGI RPM: 10,500 to 11,000 no load IDLE RPM: 2,800 to 3,000
IGNITION TIMING: fixed BREAKER POINT SETTING: no FLYWHEEL/COIL AIR GAP: 0.015 in. (0.38 mm) SPARK PLUG TYPE: Champion DJ7Y SPARK PLUG GAP: 0.025 in. (0.63 mm) CRANKSHAFT MAIN BEARINGS: Caged edle roller FUEL TANK CAPACITY: 16 oz. (473 ml)
FUEL OIL RATIO: 32:1 with Homelite oil RECOMMENDED FUEL OCTA: Regular MIX OIL SPECIFICATION: Homelite chain saw mix oil CHAIN PITCH: 3/8 in. CHAIN TYPE: Homelite BAR MOUNT PATTERN: 14 link SHORTEST GUIDE BAR SUPPLIED: 16 in. (40 cm) LONGEST GUIDE BAR SUPPLIED: 24 in. (61 cm) COLOUR SCHEME: Homelite Red
Start your chain saw correctly, because proper use and maintenance will keep it an effective tool and reduce the risk of injury. For example, remembering to move the switch to “Stop” when you’re do using the Homelite 330 will keep it safe when you have to readjust the chain or fill the tank. Use caution when starting the chain saw. 1 Move the saw at least 10 feet away from the fueling area. Move the switch to the “Run” position. 2 Grip the Homelite 330 so that the fingers and thumbs on o hand are completely around the handle behind the hand guard. 3 Move the bar so that it isn’t touching anything. The Homelite 330 shouldn’t be started if the saw is contacting any objects. 4 Push down the throttle handle on top of the handle with your free palm, and then use your fingers to hold down the trigger under the handle. 5 Push the trigger latch on the side of the handle in with your thumb and hold it in. Release the trigger under the handle, and then release the latch to start the saw. 6 Place the Homelite 330 on the ground. Continue holding the handle ar the hand guard and put your foot through the rear handle to keep it on the ground. Grasp the starter grip attached to the rope and pull it up firmly. 7 Move the choke switch to “Half” position with the hand gripping the handlebar when the engi responds by sputtering or running briefly. Move the choke to “Open” to engage the engi and keep the Homelite 330 running. 8Release the starter grip, and then grasp the back handle of the saw so your fingers are on the trigger. Lift up the saw again. 9 Squeeze the trigger to throttle the engi of the saw. Your thumb and fingers should be wrapped around different sides of the chain saw handle, with your fingers on the trigger.
