Carburetor Repair Kit for Yamaha 40-50HP 2-Stroke Outboards Carburetor Replaces Yamaha 6H4-W0093-03-00 6H4-W0093-02-00 Sierra 18-7768

Replacement part number: Mallory 9-37503; Yamaha 6H4-W0093-03-00; 6H4-W0093-02-00; Sierra: 18-7768. Fit: Designed for Yamaha 40-50HP 2-stroke Outboards Carburetor. Function: Rebuild your carburetors old part, save time and money, give your machine new power and run at a better performance. Package includes: All parts as shown in the picture. Meets and reaches to the original quality. Product Description

Includes
(3) Gaskets, (3) Caps, (3) Needle Valve Assemblies, (3) Clips, (3) Float Pins, (3) Floats, (3) Float Arm Pins, (3) Float Chamber Gaskets, (3) Screws with Washers, (3) O-Rings, (3) O-Rings (3) Pilot Screws; comes as shown in the first image
Gaskets (6H4-14198-01-00, 18-99133)
Caps (676-14966-00-00)
Needle Valve Assemblies (6H4-14590-01-00)
Clips (663-14159-00-00)
Float Pins (676-14186-00-00)
Floats (6H4-14985-01-00, 67F-14985-00-00)
Float Arm Pins (6H4-14548-00-00)
Float Chamber Gaskets (6H4-14984-00-00)
Screws with Washers (97980-04114-00)
O-Rings (93210-04230-00)
O-Rings (6H4-14147-00-00)
Pilot Screws (692-14923-00-00)
SIZE YEAR
40 HP 1989-2005
C40 HP 2002-2003
P40 HP 1998
50 HP 1989-Up
C50 HP 1998-2001
P50 HP 1991-1996
PRO 50 1989-1990
