BRIGGS and STRATTON CARBURETOR OEM CARB LAWN MOWER

SKU HYQ.00375 Category Tag

SPREAD THE LOVE

Share on facebook
Share on twitter
Share on linkedin
Share on pinterest
Share on reddit
Share on odnoklassniki

Description

BRIGGS and STRATTON CARBURETOR OEM CARB LAWN MOWER

Features??Applicable models: BRIGGS and STRATTON

SpecificationsProduct nameCARBURETOR OEM CARBMOQ1 PieceSize10x9x7cmFeatureDurableQualityHigh-QualityWeight0.148kg

Detailed Images

Carburetor working principleFirst fuel is supplied into the float chamber through strainer. Strainer works as a filter. It does not allow dust and othersuspended particles into the float chamber which can choke any fuel passage.The float maintains a constant level of fuel into float chamber. If the amount of fuel in the float chamber goes down belowdesigned limit, the float goes down which opens the fuel supply valve and allow fuel to flow into float chamber. If the fuelreaches designed limit, the float goes up, which closes the fuel supply valve and thus stop fuel supply into float chamber.The fuel discharge nozzle connects float chamber to venturi tube. The one end of fuel supply nozzle connected to the bottom of the float chamber and other one is to the venturi tube slightly above the designed fuel level in the float chamber. This will avoid overflow when engine is not running.During suction stroke air is drawn into cylinder through venturi tube. Venturi is a tube of decreasing cross section and has a minimum area at throat. The fuel supply nozzle connects at the throat of venturi tube. This air has maximum velocity at throat.Due to this high velocity, the pressure at the throat goes down below float chamber pressure.This will create a pressure difference between float chamber and venturi tube. This pressure difference is known as carburetor depression. It acts as driving force for fuel. It drives fuel from float chamber to venturi tube through fuel supply tube and the fuel is discharged into the air stream.Thefuel-air ratio depends on the size of discharge jet and metering system. So they are chosen as such, they can give desired air-fuel ratio.This air fuel mixture provided to the cylinder through throttle valve. The SI engine is a quantity governed engine. So thequantity of the mixture provided into the cylinder is controlled by the throttle valve and hence control output power.For idling or when required rich mixture, extra fuel is supplied by the idling system into venturi tube.
