Air Shock Absorber Rear Suspension Fit For Yamaha Fit For Scooter Dirt Fit For Street Bike Fit For Gokart Moped Fit For Quad ATV 150cc-750cc Universal Motorcycle Suspension Strut Motorcycle Shock Abso

Made of high material for durability and stability

Pressure can be adjusted by springs or air (nitrogen); Operation of the coil-over springs and air cylinder is helpful to reduce the shock

No instruction included, professional installation recommended

The suspension leg provides a smoother ride and better shock absorption management. The spring seat is insulated from the spring to ensure a quiet and comfortable ride

The suspension shocks struts provides a smoother ride and better overall damping management
Color:320mm Gray
Specifications:
Length of Eye to Clevis Eye Total Length Spring Thickness Spring Width WorStroke Maximum load
280mm (11″) 350mm (13 3/4″) 7mm 60mm 60mm 150kg (330 lbs)
320mm (12 5/8″) 350mm (13 3/4″) 7mm 60mm 60mm 200 kg (440 lbs)
Clevis Hole Diameter: 8mm
Clevis Inner Width: 20mm
Clevis Maximum Tensile Strength: 2,000 Kgf
Spring Stiffness: 110 kg
Air Reservoir: Adjustable
Factory Air Pressure: 0.4 Mpa
Maximum Air Pressure: 0.5 Mpa
Fitting manual is not included. installed by qualified mechanic is recommended.

Package included: 1 pcs Shock Absorbers
