49CC 2 Stroke Engine Single Cylinder Pull Start Bike Engine Motor 2 Stroke Mini Dirt Bike Engine for Pocket Bike Scooter

SKU YQ.00512 724443814306 Categories , Tag

SPREAD THE LOVE

Share on facebook
Share on twitter
Share on linkedin
Share on pinterest
Share on reddit
Share on odnoklassniki

Description

Robust and Durable – The housing is made of high-quality aluminum, which is robust, wear-resistant, scratch-resistant, and rust-proof to ensure long service life.
Specifications – Displacement: 49CC. Stroke: 2-stroke. Start Way: Pull Start. Cooling: Air Forced Cooling. Sprocket Size: 6 Teeth Fit 25H Chain.
Air Filter – It is equipped with an air filter that effectively prevents impurities from entering the cylinder and avoids running faults.
Good Heat Dissipation – It adopts an efficient cold air cooling system to ensure good heat dissipation which ensures stability over long periods of running.
Applicable Models – For 49CC 2 Stroke Pocket Bike, Mini Dirt Bike, ATV or Scooter.
Product Description
Specifications
Material: Aluminum
Color: Red
Applicable Models: For 49CC 2 Stroke Pocket Bike, Mini Dirt Bike, ATV or Scooter.
Cylinder Numbers: Single Cylinder
Stroke: 2 Stroke
Displacement: 49 CC
Start Way: Pull Start
Cooling: Air Forced Cooling
Sprocket Size: 6 Teeth Fit 25H Chain
Noise Level: Sound Pressure Level: 100.7dB(A) Sound Power Level: 116.9dB(A)
Gasoline Engine Displacement: 49.85ml/0.013gal
Maximum Power(5-15min): 1.9kw/7000rpm
Rated Power (12h Power): 1.7kw/6000rpm
Continuous Power (300h or more Power): 1.6kw/5500rpm
Overload Power (1h Power): 1.83kw/6500rpm
Speed Reduction Ratio: 1:1
No-load Speed: 12500r/min
Max. Torque: 2.7N.M/6500rpm
Max. Horsepower: 3PS
Bore Stroke: ?? 44*32.8mm/?? 1.73*1.29in
Minimum Fuel Consumption Rate: ??610 g/kW.h
Fuel: No. 90 Lead-free Gasoline
Lubricant: FC Grade Two-stroke Gasoline Engine Oil
Gasoline to Engine Oil Volume Mixing Ratio: 25:1 at Break-in Period, 30:1 after Break-In Period
Spark Plug Gap: 0.5mm/0.02in
Carburetor Type: Float Type (H117B)
Ignition Method: Electronic Ignition
Fuel Tank Volume: 1.2L/0.32gal
Dimension: 26*21.8*14.5 cm/10.23*8.58*5.7in
Net Weight: 3.6kgHighlights
Excellent Performance
Small in Size, Space Saving
Beautiful Appearance
Fine Workmanship
Non-slip Grips for Comfortable Operation
Complete Accessories, Easy to Install
T-shaped Hand Puller, Labor-saving and ConvenientPackage Included
1 x Engine
1 x Air Filter
1 Pair x Grips
1 x Throttle Cable
All Accessorequired for InstallationNotes
1. We strongly recommend professional installation. Please contact us if you have any questions.
2. Please allow the slight color difference caused by the shooting light and 1-3 cm error due to manual measurement, and make sure you do not mind before you place the order.
