3/4" Shaft Series 30 Torque Converter Driver Clutch Assembly for Coleman KT196 & CK196 196cc 6.5 Hp Go-Karts

SKU LHQ.08702 X98-6069 Category Tags ,

SPREAD THE LOVE

Share on facebook
Share on twitter
Share on linkedin
Share on pinterest
Share on reddit
Share on odnoklassniki

Description

Also known as the driver pulley.
3/4″ drive shaft diameter asymetrical pulley
The torque converter driver cutch assembly for the Coleman KT196 and CK196 196cc 6.5 Hp go-karts features a 3/4″ central aperture for the drive shaft.
Also known as the driver pulley, this clutch may also be found on other applications that run on 5.0 hp, 6.5 hp, 8.0 hp, and 9 hp engines.
Bell diameter: 4.9″ (125 mm)
This torque converter driver clutch is what is known as a Series 30 clutch assembly. A Series 30 clutch may be discerned from the very similar Series 20 by its asymmetrical pulley. The sliding sheave will be conical while the stationary sheave will be almost flat in comparison. On a Series 20 pulley, the two sheaves will both be angled.
