212cc Torque Converter Go Kart Clutch 3/4 inch 10T 40/41 & 12T 35 Chain Predator Drive Belt Pulley Replace for Manco Comet TAV2 Mini Bike - 30 Series

SPREAD THE LOVE

Share on facebook
Share on twitter
Share on linkedin
Share on pinterest
Share on reddit
Share on odnoklassniki

Description

30 Series Torque Converter Clutch Kit: This 3/4″ Torque Converter is a direct replacement fits all models of Comet TAV2 Torq-A-Verters 218353A, 219552A, 219456A, 217610A. It fits all engines with a 3/4″ Straight Crankshaft. Replaces for Comet Manco Go Karts
212cc 6.5 HP Go Kart Torque Converter Clutch Kit: Made of high quality iron and aluminum material, which is sturdy, durable, maximum torque, wear-resisting and fast heat dissipation 30-75. Engine Compatability: 6.5 HP (212cc) OHV Horizontal Shaft Gas Engine. 3/4″shaft with flat key
Toruqe Converter Belt for 6″ Driven: Length: 70.5cm / 27.76″, Outside circumference: 27 23/64″ , Width is 3/4″.??1.9cm / 0.75″). Center to Center of driver and driven: 6-15/16 to 7″
Go Kart Torque Converter Kit Included: Driver clutch bore: 3/4″, Driven unit: Overall Diameter 6″ (5/8″ driven pulley) , 2 Sprocket teeth: 10 Tooth Sprocket for #40 #41 #420 chain & 12 Tooth Sprocket for #35 Chain (Chain not included). This is a complete kit that includes both drive and driven clutch pulleys, belt, aluminum engine mount plate, built in jackshaft with sprocket
Compatible For: Comet Torque Converter kits are used in small vehicles, riding lawnmowers, small tractors, go karts, mini bikes, mini choppers, ATV, motorcycles, and waterski winches. Engagement range is approximately 2350 RPM; however, this can be adjusted from Minimum 1200 RPM – Maximum 3100 RPM by changing out springs (not included) and other adjustments Go kart torque converter clutch
??Ameetaa go kart torque converter clutch is a replacement kits Compatible for the Comet TAV2 go-kart 30 series.
??This kit comes with jackshaft sprockets for the 12T #35 or 10T #40 #41 #420 chain.
??It is made of high quality iron and aluminum,So there is a better and better heat dissipation effect
30 Series Go Kart Clutch Kit TAV2
Comet 30 series torque converter kits are bolted to most engines with horizontal shafts, including: Briggs, Clinton, Honda and Clone, Kohler, Lifan, Robin and Tecumseh motors because of their outstanding performance. Can fit many models
High standard quality
Made of high quality iron and aluminum material, which is sturdy, durable, maximum torque, wear-resisting and fast heat dissipation 30-75
Perfect fit & smooth operation
which is sturdy and durable.With this clutch,it can help you get more power out of your small engine by reducing engine load and allows higher speeds out of your small engine,smoother acceleration.
Package Includes:
1 x Drive belt
1 x 3/4″ Driver pulley
1 x 5/8″ Driven pulley 6″ diameter
1 x Plastic Assy Cover
1 x Full Mounting hardware Kit
1 x 10 Tooth Sprocket for #40 #41 #420 chain (Chain not included)
1 x 12 Tooth Sprocket for #35 Chain (Chain not included)
1 x Aluminum Mounting Bracket Plate
Replace OE Number
Comet TAV2 Torq-A-Verters 218353A
219552A, 219456A
217610A, 203814A 30-75
Specific size
Length: 27.76″/70.5cm
Outside Circumference: 27 23/64″
Width: 3/4″(0.75″/1.9cm)
Diameter between driver & driven: 6-15/16 to 7″
Recommended Engine
— 6.5 HP (212cc) OHV Horizontal Shaft Gas
— Engine. 3/4″shaft with flat key
— Engagement range is approximately 2350 RPM; however, this can be adjusted from Minimum 1200 RPM – Maximum 3100 RPM by changing out springs (not included) and other adjustments
Sprocket Teeth
2 Sprocket teeth: 10 Tooth Sprocket for #40 #41 #420 chain & 12 Tooth Sprocket for #35 Chain
Driven Clutch
Driver clutch bore: 3/4″, Driven unit: Overall Diameter 6″ (5/8″ driven pulley)
Fitment
Most engines with a horizontal shaft including: Briggs, Clinton, Honda and clones, Kohler, Lifan, Robin, and Tecumseh motors
Ameetaa
Ameetaa
Ameetaa
Ameetaa
Ameetaa
Tooth
1 x 12 Tooth & 1 x 10 Tooth
1 x 10 Tooth
1 x 12 Tooth
1 x 12 Tooth
1 x 10 Tooth
Fits
3/4″ Straight Crankshaft
3/4″ Straight Crankshaft
3/4″ Straight Crankshaft
Minibike, Go Kart, Lawnmower
Minibike, Go Kart, Lawnmower
Fits Chain
35 Chain&40/41/420 Chain
40 /41 /420 Chain
35 Chain
35 Chain
40/41/420 Chain
Go with Chain
No
No
No
Yes
Yes
