1" Go Kart Torque Converter Clutch Driver Pulley w/Comet TAV2 30 Series 12T #35 & 10T #40/41/420 Chain Replacement for Small tractor Lawnmowers ATV Mini Bike

You will Get
1 x Plastic Cover
1 x 1″ Driver Pulley
1 x 5/8″ Driven Pulley (6″ Diameter)
1 x 10 Tooth Sprocket for #40/41/420 Chain
1 x 12 Tooth Sprocket for #35 Chain
1 x Aluminum Mounting Plate
1 x Mounting Hardware Kit
1 x Drive Belt
Specifications
Drive clutch bore: 1″(25.4mm )
Driven unit: Diameter 6″ (5/8″ driven pulley)
Engagement range: 2350??200 RPM
Engine horsepower: 2.5HP-8HP
Cogged belt: Asymmetrical type
Easy to Install
Size Detail
Length: 70.5cm / 27.76″
Width: 3/4″(1.9cm/0.75″)
Outside Circumference: 27 23/64″
Center to Center of driver & driven: 6-15/16 to 7″
Replace Part Numbers
Comet 219552A & Comet 219554A
Comet 203814A & Comet 217610A
Comet 218353A & Comet 219456A
Installation Steps
Step 1: Remove the old clutch kit

Step 2: Use four M8*25 screws to fix the bracket to the four standard threaded holes of the engine crankcase. If necessary, the stand can be rotated up or down.

Step 3: Disconnect the chain at an appropriate length to bypass the sprocket on the T.A.V and the final drive sprocket. Join the chain through the main link. Move the engine forward or backward to obtain the correct tension.

Step 4: Place the washer (provided with the kit) on the crankshaft to align the driving clutch with the driven unit.

Step 5: Separate the driver and place the flat pulley on the crankshaft. Slide the belt over the uprights of the driven device and the drive device. Install 4 spline hubs “D” on the outside. (Important: Make sure the bronze idler bushing on TAV 30-75 is in place. Not required for TAV 30-100.)

Step 6: Place the other half of the drive unit on the crankshaft. Align the outer cover with the “D” part of the hub, and install the fixing bolts and washers.
